STONET ST3118GS-D Switch 16 puertos 10/100/1000 Mbps +2 Slot SFP Giga 13", DIP VLAN, incluye soportes para Rack
ST3118GS-D
New
Stonet ST3118GS-D Gigabit Ethernet Switch 10/100/1000 Mbps+ 2 Giga SFP Slots
16 ports 10/100/1000 Mbps AUTO MDI/MDI-X
13-inch Rack Mount Format, includes mounting brackets
MAC Address Table 2 Kb., Switching 36 Gbps
Supports 802.3x Full Duplex and Flow Control
DIP VLAN port isolation
In Stock
- Remove this product from my favorite's list.
- Add this product to my list of favorites.
More info
The Stonet ST3118GS-D unmanaged desktop switch provides 16 adaptive 10/100/1000M RJ45 ports and 2 SFP slots (modules not included).
Stonet ST3118GS-D Gigabit Ethernet Switch 10/100/1000 Mbps+ 2 Giga SFP Slots
16 ports 10/100/1000 Mbps AUTO MDI/MDI-X
13-inch Rack Mount Format, includes mounting brackets
MAC Address Table 2 Kb., Switching 36 Gbps
Supports 802.3x Full Duplex and Flow Control
DIP VLAN port isolation
Equipped with standard 19-inch rack lugs, it can be installed in cabinets. It is suitable for a variety of network environments, supporting longer-range, faster, and more stable transmission, and is primarily recommended for use in small and medium-sized offices.
- FORMAT
- Rack 13
- ETHERNET SPEED
- GIGABIT
- ETHERNET PORTS
- 16
- Warranty
- 3-year warranty
- FIBER SPEED
- SFP 1.25 Gb
Stonet ST3118GS-D Technical Specifications
Hardware
Interface
16 * 10/100/1000M RJ45 port
2 * gigabit SFP
LED
PWR
1X-18X
Power Supply
100-240V AC 0.5A 50/60Hz
Dimensions (L x W x H)
490 * 365 * 280mm
Switching Features
Standard
IEEE802.3,IEEE802.3u,IEEE802.3z,IEEE802.3x
Backplane bandwidth
36Gbps
Packet forwarding rate
26.78Mpps
Data Transmission Rate
10Mbps(Half-duplex and Full-duplex)
100Mbps(Half-duplex and Full-duplex)
1000Mbps (Full-duplex)
Model VLAN
Normal mode (default)
Port VLAN(On):Port Vlan function is enabled: Ports 1-24 are isolated from each other and can only communicate with SFP1 and SFP2. SFP1 and SFP2 are able to communicate freely
Others
Environment
Operating Temperature: 0 ~40
Storage Temperature: -20 ~ 70
Operating Humidity: 10%~90% RH non-condensing
Storage Humidity: 5%~90% RH non-condensing
